PatrionPlus inkjet System

The Marsh PatrionPlus large character printing system is designed to meet your expanding needs. The advanced printer technology in this system has unique printhead flexibility that allows you to meet numerous production line applications with the versatility to print dot matrix or fully formed, high-resolution characters from one printing system.

Description

Specification
Value
High Resolution Printhead
     Print Speed6 to 61 m/min (20 to 200 ft/min)
     Character Height6 mm – 50 mm (0.25 in – 2.0 in)
     SubstratePorous only
     Ink Capacity500 mL (17 fl oz) bottle
Low Resolution Printhead
     Print Speed6 to 61 m/min (20 to 200 ft/min)
     Character Height10 mm – 50 mm (0.37 in – 2.0 in)
     SubstratePorous and non-porous
     Ink Capacity18.9 L (5 gallons)
Alphanumeric Text1 to 4 lines per printhead
Standard User InterfaceQWERTY keyboard with LCD display
Standard CommunicationRS232
Leader/Follower Printhead Control CapabilityUp to 16 printheads

Brand

Video Jet
